Model: MR-DF160
This electric coin cell crimping machine mainly used in the production of samples of laboratory battery materials for button batteries, capacitor scientific research sealing, and can also be used for small-scale trial production in factories. The electric method saves effort, you can also change the die for dry powder tablets, wet powder tablets, press molding, riveting and other operations.
Standard configuration can be used forthe CR20XX series coin cells such as CR2016, CR2025, and CR2032. Replace some of the mold parts can crimping 2450, 2430 and other button batteries, as well as disassemble the mold.
* If there is no obstacle (skateboard) in the glove box Φ360 transition bin, it can pass directly through the transition bin, with small volume and easy operation
|
|
Electric Coin Cell Crimping Machine MR-DF160 |
|
|
Single-phase voltage 110V ~ 220V AC ± 10%; frequency 50Hz / 60Hz |
|
|
100W |
|
|
Max. 1200Kg, digital display can be set |
|
|
20mm |
|
|
CR20 crimping mold (CR2016, CR2025, CR2032), |
|
|
|
|
|
L250*W185*H450 mm |
|
|
30kg |
|
|
|
|
|
1. Frequently wipe the dirt on the guide post and other moving parts, keep it clean, and lubricate to keep the movement smooth.
2. When the electric sealing machine is not used, turn off the power and return the movable template to the initial position. If it is not used for a long time, remove the upper mold screw and take out the sealing mold for cleaning, and apply oil to keep the sealing molding surface clean and smooth.
4. Regularly check the screws, nuts, pins and other fasteners on the electric sealing machine to prevent loosening and prevent machine quality accidents and personal accidents.
5. It is strictly forbidden to extend your hands and other parts to the dangerous area of the guide post, slide, and sealing during operation to cause personal injury. Do not allow two or more people to operate during operation to avoid accidental injury.
